Supply High Quality Outdoor Aerial Fiber Splice Closure with PLC splitter
- H017 Aerial Weather tight Splice Closures are designed for aerial, strand-mount FTTH drop locations where drop cables are spliced to distribution cables.
- These free breathing closures combine grommet cable sealing technology and splice tray, the splitter module is also available.
- H017 Aerial Weather tight Splice Closures are suitable for special feature with SSW cable.
- Closure adopts hinge/buckle mechanism which makes dismantling/assembling easy
- Convenient attachable splitter module with 1:8 splitter module & 1:16 splitter module for drop cable installation.
- Re-useable grommet sealing open and close easily for adding or removing drop cables providing efficient cable installation with no mess.
Specification
| Model | FTT-H017 |
| Dimension | 601X163X88 (LxWxH) |
| Cable input | 4×4 port |
| Cable Output | 8×8 port(Drop cable) |
| Splice tray | 26 core (52 Core-Double Layer) |
| Splitter box | 1×8PLC & 1×16PLC |
| Type | Aerial type |
*Fiber optic boxes price is as reference, may changed expensive or cheaper caused by dollar exchange rate and other cost.
*Price is based on 40HQ order, you can choose different type to mix in one container.
*MOQ: 10 piece.
*If your order is different from 40HQ, please contact us to get best price.
